Portable Dry Chemical Powder Based (SP Type) Fire Extinguisher ISI / ISO / CE (As Applicable)
Images are indicative. Final finish may vary by batch (as per standards).
MIST EXTINGUISHERS New ABC Powder Stored Pressure (SP)

Portable Dry Chemical Powder Based (SP Type) Fire Extinguisher

Dispatch 2–3 days

AMTEX Stored Pressure (SP) ABC dry chemical powder extinguisher for Class A, B, C and electrically started fires. MAP mono ammonium phosphate powder with controllable discharge and multiple size options.

Key Point
Multi-class ABC powder protection
Key Point
Controllable discharge with UGTS gauge
Key Point
Available sizes: 1kg, 2kg, 4kg, 6kg, 9kg
Contact for price
Genuine warranty
Get bulk / project quote
Pan-India shipping
Audit assistance
Upgrade options
Product Overview-Product Features

Portable Dry Chemical Powder Based (SP Type) Fire Extinguisher

Portable Dry Chemical Powder Based (Stored Pressure Type) Fire Extinguisher

An ABC powder fire extinguisher is a multi-purpose extinguisher and is one of the most common extinguishers to have on hand.

A powder extinguisher sprays a very fine chemical powder composed most commonly of monoammonium phosphate (MAP). This blankets the fire and suffocates it.

Powder extinguishers are effective for Class A, B and C fires. Since powder is not an electrical conductor and can break the chain reaction in liquid or gas fires, it is also suitable for electrically started fires.

  • Suitable for A, B, C and electrically started fires
  • IS:15683 (2018) with latest amendments
  • MAP Mono Ammonium Phosphate dry chemical powder
  • BIS Approved, ISI & CE marked
  • Hydraulically tested and anti-corrosive treated
  • High quality Pure Polyester (PP) powder coating
  • Brass chrome plated valve with squeeze operation
  • Unique Gauge Testing System (UGTS) and controllable discharge
  • Rubber braided hose (flexible & crack resistant)
  • Conformity standard: IS:15683:2018 (Latest)

Available sizes: 1Kg, 2Kg, 4Kg, 6Kg, 9Kg

Refilling must be done by Manufacturer or Authorised Skilled Agent. Technical specifications subject to change due to continuous improvement.

Key Highlights
  • Multi-Class Protection
    Effective on Class A, B, C and electrically started fires
  • MAP ABC Powder
    Mono Ammonium Phosphate powder blankets and suffocates the fire
  • UGTS + Pressure Gauge
    Gauge and UGTS help verify readiness and enable controllable discharge
  • Squeeze Operation
    Brass chrome plated valve with easy squeeze activation
  • Certified & Tested
    BIS approved, ISI & CE marked; hydraulically tested & anti-corrosive treated

Works on

Suitable across multiple fire classes (as per application).
Class-A
Wood, paper, cloth and other solid combustibles
Class-B
Flammable liquids like petrol, paints, solvents
Class-C
Flammable gases
Electrical
Electrically started fires
*Use from a safe distance and follow safety guidance / site policy.

Technical & Performance Data

Reference configuration data (subject to continuous improvements).
Parameter AS/01 & AS/02 AS/04 AS/06 AS/09
CAPACITY 1KG/2KG 4KG 6KG 9KG
EXTINGUISHING AGENT ABC POWDER ABC POWDER ABC POWDER ABC POWDER
PROPELLANT NITROGEN GAS (As per IS:1747) NITROGEN GAS (As per IS:1747) NITROGEN GAS (As per IS:1747) NITROGEN GAS (As per IS:1747)
APPLICABLE ON FIRES A, B, C, & Electrical Started Fire A, B, C, & Electrical Started Fire A, B, C, & Electrical Started Fire A, B, C, & Electrical Started Fire
OPERATING TEMPERATURE -30 C to +60 C -30 C to +60 C -30 C to +60 C -30 C to +60 C
FIRE RATING MIN 1A& 34B MIN 3A& 55B MIN 3A& 89B MIN 4A& 144B
HYDROSTATIC TEST PRESSURE 35 BAR 35 BAR 35 BAR 35 BAR
BURST PRESSURE MIN 55 BAR MIN 55 BAR MIN 55 BAR MIN 55 BAR
WORKING PRESSURE 15 BAR 15 BAR 15 BAR 15 BAR
IMPACT TEST PASSED PASSED PASSED PASSED
PRESSURE CYCLING TEST PASSED PASSED PASSED PASSED
TAPPING TEST PASSED PASSED PASSED PASSED
INTERMITTENT DISCHARGE TEST PASSED PASSED PASSED PASSED
COATING EPOXY POWDER COATING EPOXY POWDER COATING EPOXY POWDER COATING EPOXY POWDER COATING
VALVE / CAP CONSTRUCTION FORGING AND MACHINING FORGING AND MACHINING FORGING AND MACHINING FORGING AND MACHINING
DISCHARGE MECHANISM SQUEEZE GRIP/THUMB TRIGGERED SQUEEZE GRIP/THUMB TRIGGERED SQUEEZE GRIP/THUMB TRIGGERED SQUEEZE GRIP/THUMB TRIGGERED
METHOD OF OPERATION EASY ACTIVATION EASY ACTIVATION EASY ACTIVATION EASY ACTIVATION
BODY THICKNESS AS PER IS:15683 AS PER IS:15683 AS PER IS:15683 AS PER IS:15683
HELIUM LEAK DETECTION TESTING YES YES YES YES
LEAKAGE TEST (Latest) YES YES YES YES
HEIGHT (APPROX.) Approx. 335mm/365mm Approx. 440 mm Approx. 460 mm Approx. 550 mm
GROSS WEIGHT (APPROX.) Min. 2.100 Kg/Min. 3.200 Kg Min. 6.200Kg Min. 8.400 Kg Min 12.300 Kg
AVERAGE DISCHARGE TIME(MED) MIN 9 SEC MIN 13 SEC MIN 13 SEC MIN 13 SEC
AVERAGE RANGE OF THROW 1-2 MTR. 2-3 MTR. 2-5 MTR. 2-6 MTR.
AVERAGE % DISCHARGE MIN 90% MIN 90% MIN 90% MIN 90%
MOUNTING BRACKET YES YES YES YES
PRESSURE GAUGE YES YES YES YES
READYNESS OF WORKING SHOWING SHOWING SHOWING SHOWING
HOSE ASSEMBLIES (ONLY NOZZLE) YES (MORE THAN 400 MM) YES (MORE THAN 400 MM) YES (MORE THAN 400 MM)
SAFETY LOCKING DEVICE YES(20 N TO 100 N) YES(20 N TO 100 N) YES(20 N TO 100 N) YES(20 N TO 100 N)
CONFORMING STANDARDS IS:15683(LATEST) IS:15683(LATEST) IS:15683(LATEST) IS:15683(LATEST)
NABL LAB APPROVAL (BIS APPROVED LAB) YES YES YES YES
APPROVALS BIS,CE,EN & ISO BIS,CE,EN & ISO BIS,CE,EN & ISO BIS,CE,EN & ISO
REFILLING SCHEDULE AS PER IS:2190 AS PER IS:2190 AS PER IS:2190 AS PER IS:2190
Important
It is mandatory for the extinguisher to be refilled by Manufacturer or an Authorised Skilled Agent. Specifications may change with time due to continuous product improvisation.
