Portable Clean Agent Based (SP Type) Fire Extinguisher
Residue-free, non-conductive HFC236fa (FE36) clean agent extinguisher for Class A, B, C and electrically started fires. Ideal for server rooms, electrical panels and sensitive electronics.
Portable Clean Agent Based (SP Type) Fire Extinguisher
Portable Clean Agent Based (Stored Pressure Type) Fire Extinguisher
A clean agent fire extinguisher is a type of gaseous fire suppression. Stored in liquid form, when discharged it converts into gas which is non-conductive, safe to use while humans are present, leaves no residue and has a short atmospheric lifetime.
Clean agents extinguish fire by reducing oxygen concentration and interrupting the chain reaction. Because it is non-conductive and residue-free, it is ideal for rooms filled with electrical and computer equipment.
AMTEX brand Clean Agent extinguishers contain HFC 236fa (DU Pont FE36) with zero ODP (Ozone Depletion Potential). These extinguishers are lightweight yet deliver strong throw to penetrate grills and meshes, making them highly effective for sensitive environments.
Key Benefits: Residue-free, zero collateral damage, controllable discharge and safe for sensitive equipment. Pressure gauge ensures readiness of working condition.
- Fights Class A, B, C and electrically started fires
- Zero damage and residue-free
- Controllable discharge mechanism with squeeze operation
- BIS Approved, ISI & CE marked
- Hydraulically tested and anti-corrosive treated
- High quality Pure Polyester (PP) powder coating
- Unique Gauge Testing System (UGTS)
- Conformity standard: IS:15683:2018 (Latest)
Refilling must be done by Manufacturer or Authorised Skilled Agent. Technical specifications subject to change due to continuous improvement.
-
Electronics Safe
Non-conductive clean agent safe for server rooms and electrical panels
-
Residue-Free
Leaves no residue and causes zero collateral damage
-
HFC236fa (FE36) Clean Agent
High-performance DU Pont FE36 gas with strong throw and rapid knockdown
-
Eco Friendly (Zero ODP)
Zero ozone depletion potential and short atmospheric lifetime
-
Gauge + UGTS Readiness
Pressure gauge and UGTS help verify readiness of working condition
Works on
Recommended For
- Schools
- Server Rooms
- Electrical Panels
- Offices & Banks
- Hotels
- Residences
- Restaurants
- Parking Garages
- Repair Workshops
- Construction Sites
- Electrical Equipment Rooms
- Machine Operations
Technical & Performance Data
| Parameter | C.A. (S.P.) 2 |
|---|---|
| CAPACITY | 2KG |
| EXTINGUISHING AGENT | HFC236fa (DU pont-FE36) |
| PROPELLANT | NITROGEN GAS (As per IS:1747) |
| APPLICABLE ON FIRES | A, B, C, & Electrical Started Fire |
| OPERATING TEMPERATURE | -30 C to +60 C |
| FIRE RATING | MIN 1A& 21B |
| HYDROSTATIC TEST PRESSURE | 35 BAR |
| BURST PRESSURE | MIN 55 BAR |
| WORKING PRESSURE | 15 BAR |
| IMPACT TEST | PASSED |
| PRESSURE CYCLING TEST | PASSED |
| TAPPING TEST | PASSED |
| INTERMITTENT DISCHARGE TEST | PASSED |
| COATING | EPOXY POWDER COATING |
| VALVE / CAP CONSTRUCTION | FORGING AND MACHINING |
| CAN CONSTRUCTION | DEEP DRAWN AND MIG WELDED |
| DISCHARGE MECHANISM | SQUEEZE GRIP/THUMB TRIGGERED |
| METHOD OF OPERATION | EASY ACTIVATION |
| BODY THICKNESS | AS PER IS:15683 |
| HELIUM LEAK DETECTION TESTING | YES |
| LEAKAGE TEST | YES |
| HEIGHT (APPROX.) | Approx.350 mm |
| GROSS WEIGHT (APPROX.) | MIN.3.100 Kg |
| AVERAGE DISCHARGE TIME(MED) | MIN 9 SEC |
| AVERAGE RANGE OF THROW | 1-2 MTR. |
| AVERAGE % DISCHARGE | MIN 90% |
| MOUNTING BRACKET | YES |
| PRESSURE GAUGE | YES |
| READYNESS OF WORKING | SHOWING |
| HOSE ASSEMBLIES | (ONLY NOZZLE) |
| SAFETY LOCKING DEVICE | YES(20 N TO 100 N) |
| CONFORMING STANDARDS | IS:15683(LATEST) |
| NABL LAB APPROVAL (BIS APPROVED LAB) | YES |
| APPROVALS | BIS,CE,EN & ISO |
| REFILLING SCHEDULE | AS PER IS:2190 |
