ISI / ISO / CE (As Applicable)
Images are indicative. Final finish may vary by batch (as per standards).
MIST EXTINGUISHERS
New
CO2
WT Type
Portable Carbon Dioxide Based (WT Type) Fire Extinguisher [2Kg]
Residue-free CO2 extinguisher for Class B, Class C and electrical fires. Non-conductive clean agent with controllable squeeze/wheel discharge—ideal for offices, UPS rooms and computer centres.
Key Point
Clean agent (no residue, no clean-up)
Key Point
Non-conductive for electrical safety
Key Point
Controllable squeeze/wheel discharge
Contact for price
Genuine warranty
Pan-India shipping
Audit assistance
Upgrade options
Product Overview-Product Features
Portable Carbon Dioxide Based (WT Type) Fire Extinguisher [2Kg]
Portable Carbon Dioxide (CO2) Fire Extinguisher (WT Type) - 2Kg
A carbon dioxide fire extinguisher (CO2) is one of the cleanest types of extinguishers to use as it leaves no residue and requires no clean-up.
CO2 extinguishers work by displacing oxygen around the fire, effectively suffocating it. They are perfect for Class B fires involving flammable liquids and for electrical fires.
Key Highlights
- Suitable for Class B, C and electrically started fires
- CO2 gas as per IS:15222
- No residue (no clean-up required)
- Non-conductive agent for electrical use
- BIS Approved and ISI & CE marked
- Hydraulically tested as per standard
- Brass chrome plated valve with squeeze/wheel operation
- Controllable discharge mechanism
- Rubber braided hose for flexibility and durability
- Conformity standard: IS:15683:2018 (Latest)
Ideal Use: Homes, offices, buildings, warehouses, UPS and computer centres.
Refilling must be done by Manufacturer or Authorised Skilled Agent. Technical specifications are subject to change due to continuous improvement.
Key Highlights
-
No Residue
Clean CO2 discharge leaves no residue and requires no clean-up
-
Electrical Safe
Non-conductive agent suitable for electrical fires without risk to operator
-
Oxygen Displacement
CO2 suffocates fire by displacing oxygen around flames
-
Controllable Discharge
Squeeze grip / wheel type valve enables controlled discharge
-
Certified & Tested
BIS approved, ISI & CE marked; hydraulically tested, leak tested
Works on
Suitable across multiple fire classes (as per application).
Class-B
Flammable liquids like petrol, paints, solvents
Class-C
Flammable gases
Electrical
Electrically started fires
*Use from a safe distance and follow safety guidance / site policy.
Recommended For
Residential • Commercial • Institutional • Industrial
- Schools
- Offices & Banks
- Hotels
- Petrol Pumps
- Restaurants
- Parking Garages
- Oil & Petrochemical Factories
- Repair Workshops
- Construction Sites
- Welding Areas
- Electrical Equipment Rooms
- Machine Operations
Available Sizes
2KG
Available Variants
WT Type, CO2 Stored Pressure
Technical & Performance Data
Reference configuration data (subject to continuous improvements).
| Parameter | CO2ST2 | CO2ST4.5 |
|---|---|---|
| CAPACITY | 2KG | 4.5KG |
| EXTINGUISHING AGENT | CO2 GAS | CO2 GAS |
| PRESSURE TYPE | STORED PRESSURE | STORED PRESSURE |
| APPLICABLE ON FIRES | B, C, & Electrical Started Fire | B, C, & Electrical Started Fire |
| OPERATING TEMPERATURE | -30 C to +60 C | -30 C to +60 C |
| FIRE RATING | MIN 21B | MIN 55B |
| HYDROSTATIC TEST PRESSURE | 250 BAR | 250 BAR |
| WORKING PRESSURE | 60-70 BAR | 60-70 BAR |
| IMPACT TEST | PASSED | PASSED |
| VIBRATION TEST | PASSED | PASSED |
| TAPPING TEST | PASSED | PASSED |
| INTERMITTENT DISCHARGE TEST | PASSED | PASSED |
| COATING | ANTI CORROSIVE | ANTI CORROSIVE |
| VALVE / CAP CONSTRUCTION | FORGING AND MACHINING (as per IS:3224) | FORGING AND MACHINING (as per IS:3224) |
| BODY CONSTRUCTION | PESO,CCOE APPROVED (CONFIRMING IS:7285) | PESO,CCOE APPROVED (CONFIRMING IS:7285) |
| DISCHARGE MECHANISM | SQUEEZE GRIP/WHEEL TYPE (CONTROLLABLE) | SQUEEZE GRIP/WHEEL TYPE (CONTROLLABLE) |
| METHOD OF OPERATION | EASY ACTIVATION | EASY ACTIVATION |
| BODY THICKNESS | AS PER IS:7285 | AS PER IS:7285 |
| HELIUM LEAK DETECTION TESTING | YES | YES |
| LEAKAGE TEST | YES | YES |
| HEIGHT (APPROX.) | Approx. 550mm | Approx. 700mm |
| GROSS WEIGHT (APPROX.) | Min. 8.00 Kg | Min. 16.00 Kg |
| AVERAGE DISCHARGE TIME(MED) | MIN 9 SEC | MIN 13 SEC |
| AVERAGE RANGE OF THROW | 2-3 MTR. | 2-4 MTR. |
| AVERAGE % DISCHARGE | MIN 98% | MIN 98% |
| MOUNTING BRACKET | YES | YES |
| HOSE ASSEMBLIES | BEND HORN & HORN | HOSE PIPE & HORN (MORE THAN 400 MM) |
| SAFETY LOCKING DEVICE | YES(20 N TO 100 N) | YES(20 N TO 100 N) |
| CONFORMING STANDARDS | IS:15683(LATEST) | IS:15683(LATEST) |
| NABL LAB APPROVAL (BIS APPROVED LAB) | YES | YES |
| APPROVALS | BIS,CE,EN & ISO | BIS,CE,EN & ISO |
| REFILLING SCHEDULE | AS PER IS:2190 | AS PER IS:2190 |
Important
It is mandatory for the extinguisher to be refilled by Manufacturer or an Authorised Skilled Agent.
Specifications may change with time due to continuous product improvisation.
