Abc Powder Clean Agent Based Ceiling Mounted Standalone Modular Fire Suppression Systems
AMTEX Brand
Product Overview-Product Features
- There will always be areas in a workplace where the chances of detecting a fire early are very few and human traffic, very low - factories with large storage areas and server rooms, for instance. If a fire breaks out in such areas, putting it out becomes almost impossible.
- AMTEX Brand Ceiling Mounted extinguishers, with their automatic detection and activation feature prevent such an occurrence. Because they are ceiling mounted, they are also useful in areas that are beyond the range of normal fire extinguishers, such as high chemical stacks
- AMTEX presents the modular type Automatic fire extinguisher .It keeps guard, extinguishes fire quickly and efficiently when the Fire temperature reaches the temperature sensing bulb temperature. These modules are very useful especially in closed and remote places where fire could cause extensive damage if not detected and extinguished in time.
- In the event of a fire, AMTEX brand Ceiling Mounted extinguishers activate automatically, spraying the extinguishant with maximum force, ensuring that the fire is brought under control rapidly and efficiently.
- The ABC powder variant of these extinguishers use 90% concentration of Mono Ammonium Phosphate, these extinguishers maximize your fire fighting power against virtually all classes of fire.
- Whereas the Clean agent based variant of these extinguishers use HFC236fa / HCFC123 gas that leave no collateral damages at all.
- World class quality: Comes with ISO 9001 and CE certification, and conforms to ISI standards. Comprehensive Helium Tests and Leak Tests also guarantee that the products you buy are manufactured according to the world's most stringent quality standards.
- Fights Class A, B, C and electrically started fires
- Automatic Discharge Mechanism
- Pressure gauge: Ensure for readiness of working Condition.
- Available in 5kg & 10kg (ABC Powder & Clean Agent)
Works on:
Class-A
Class-B
Class-C
Electrically Started Fires
Technical & Performance Data :
| MODEL/MAKE | MODULAR(S.P.) /5/6 | MODULAR(S.P.) /9/ 10 |
|---|---|---|
| CAPACITY | 5//6KG | 9/10KG |
| EXTINGUISHING AGENT | ABC POWDER | ABC POWDER |
| PROPELLANT | NITROGEN GAS (As per IS:1747) | NITROGEN GAS (As per IS:1747) |
| APPLICABLE ON FIRES | A, B, C, & Electrical Started Fire | A, B, C, & Electrical Started Fire |
| OPERATING TEMPERATURE | -30 °C to +60 °C | -30 °C to +60 °C |
| FIRE RATING | MIN 3A& 89B | MIN 3A& 89B |
| HYDROSTATIC TEST PRESSURE | 35 BAR | 35 BAR |
| BURST PRESSURE | MIN 55 BAR | MIN 55 BAR |
| WORKING PRESSURE | 15 BAR | 15 BAR |
| PRESSURE CYCLING TEST | PASSED | PASSED |
| TAPPING TEST | PASSED | PASSED |
| COATING | EPOXY POWDER COATING | EPOXY POWDER COATING |
| VALVE / CAP CONSTRUCTION | FORGING AND MACHINING | FORGING AND MACHINING |
| CAN CONSTRUCTION | DEEP DRAWN AND MIG WELDED | DEEP DRAWN AND MIG WELDED |
| DISCHARGE MECHANISM | AUTOMATIC | AUTOMATIC |
| METHOD OF OPERATION | AUTOMATIC | AUTOMATIC |
| CAST ANALYSIS OF THE BODY | C: 0.25 % max carbon, S: 0.05 % max P:0.05%max of phosphorus) | C: 0.25 % max carbon, S: 0.05 % max P:0.05%max of phosphorus) |
| HELIUM LEAK DETECTION TESTING | YES | YES |
| LEAKAGE TEST(Latest) | YES | YES |
| GROSS WEIGHT (APPROX.) | Min.7.000kg | Min.13.500 Kg |
| AVERAGE DISCHARGE TIME(MED) | MIN 9 SEC | MIN 9 SEC |
| AVERAGE % DISCHARGE | MIN 85% | MIN 85% |
| MOUNTING BRACKET | YES | YES |
| PRESSURE GAUGE | YES | YES |
| READYNESS OF WORKING | SHOWING | SHOWING |
| APPROVALS | BIS,CE,EN & ISO | BIS,CE,EN & ISO |
| REFILLING SCHEDULE | AS PER IS:2190 | AS PER IS:2190 |
- It is mandatory for the extinguisher to be refilled by Manufacturer or Authorised Skilled Agent.
- Technical specifications are subject to change with time due to our continuous product improvisation initiatives
Application Areas: Schools, Offices & Banks, Hotels, ,Restaurants, Parking Garages, Repair Workshop, Construction Site, Materials Handling Vehicles, Maintenance Facilities, Propane Filling and Storage, Welding Areas, Petrol and Oil Pumps, Paint Processing Areas, Electrical Equipment Rooms , Machine Operations etc.
